6DOF Stewart Motion Platform Kits 6D-01
We typically have two types of the actuators with both stroke 450mm, but they are direct inline and foldback. For foldback actuators, the biggest advantages are pulley and gear transmissions, we are flexbile to adjust the speed and force based on limited motor watts, and of course, it will be also a little lower by its fully body dimension compared with direct inline ones.
A lot of guys are interested on the 6dof, cause it could be making flight sims much more immersive, with this great demand, we open to share 2 kinds of classical design of 6DOF sunken type platforms. You can download the pdf file listed below, check the dimensions,where to fixed the universal joints,what’s the best CG dimenion,and motion platform radius,etc. This will make complicated work much more easy to achieve.
If you guys want heavy duty or customized motion platforms, please let us know, PT-Actuator is free to provide you a constructive/pratical solution.
- Product Weight (lbs): 430
- Length (Inches): 37.8
- Width (Inches): 22.1
- Height (Inches): 19.3
